THC Ib Lub Taub Hau Pneumatic Filling Tshuab

1. Lub zog yog tsav los ntawm cov txheej txheem ruaj khov thiab lub tshuab hluav taws xob ceev tswj lub cev muaj zog, ua kom muaj kev ua haujlwm zoo thiab tsis muaj suab nrov. Qhov ceev tuaj yeem hloov kho tsis tu ncua.

2. Zoo metering twj tso kua mis, raug ± 0.5ml.

3. Lub ntim ntim tuaj yeem nyob ntawm 1-1000 ml, thiab lub tshuab filling nrog cov lus qhia tshwj xeeb tuaj yeem raug xaiv kom ua tiav cov filling. Lub tshuab yog portable thiab tuaj yeem muab tso rau ntawm qhov xav tau. Lub ntim ntim tuaj yeem hloov kho me ntsis kom tau raws li cov neeg siv khoom sib txawv.

4. Fais fab mov: 220v

5. Zuag qhia tag nrho dimension: 180 × peb puas × 480mm

6. Nyhav: 13kg

1. Cov qauv yooj yim thiab txhim khu kev qha nrog ob peb qhov yuam kev;

2. Lub khob hliav qab piston yog saws, nrog kev ua tau zoo sealing, yog kua dispensing ntim, thiab yooj yim kua ntim hloov;

3. Cov khoom sib txuas ua kua yog ua los ntawm cov hlau tsis huv thiab yooj yim rau kev thauj khoom thiab tshem tawm, tso cai rau kom tsis muaj menyuam;

4. Lub tog raj kheej kheej kheej, thawb pas nrig, thiab piston yog ua los ntawm cov hlau tsis muaj steel, uas yog corrosion-resistant thiab hnav-resistant;

5. Ceev nruam adjustable, yooj yim rau kev khiav lag luam.

Cov cuab yeej no tuaj yeem pib siv ko taw hloov lossis los ntawm nias lub sijhawm relay.

Cov roj txhaj tshuaj tuaj yeem hloov kho los ntawm cov roj txhaj tshuaj kho tus pas nrig. Tom qab kev hloov kho, ntsuas qhov ntsuas tus pas ntsuas.

Qhov ceev ntawm cov roj txhaj tshuaj thiab nqus tau tuaj yeem hloov kho los ntawm lub tog raj kheej tswj lub valve, uas yog ceev ceev hauv kev coj ua clockwise thiab qeeb hauv kev coj ua counterclockwise.

Parameter Description: OP yog lub sijhawm ON, CL yog lub sijhawm OFF, thiab LOP yog tus lej ntawm lub voj voog (1 txog 9999, "------")

Sawv cev infinite cycles)

Lub sij hawm ntau: 0.01s (tsawg kawg) txog 9999 feeb (siab tshaj) tsis tu ncua adjustable

(1) Nias thiab tuav lub khawm kom nkag mus rau qhov chaw teeb tsa interface;

(2) Ua ntej, teeb tsa hom kev ua haujlwm, thiab hom kev ua haujlwm yuav flash los ceeb toom koj. Teem hom kev ua haujlwm los ntawm nias qhov ntxiv / rho tawm / yuam sij luv luv

Hom kev ua haujlwm;

(3) luv luv nias lub khawm kom xaiv hom kev ua haujlwm thiab nkag mus rau qhov system parameter teeb tsa;

(4) Nyob rau hauv qhov system parameter teeb interface, luv nias lub teeb qhov tseem ceeb hloov qhov system parameter hloov, luv xovxwm / ntev nias

Ntxiv / rho tawm / nias kom hloov kho; (Faj seeb: luv nias ntawm qhov teeb tsa khawm hauv P0 rau P3 / P8 / P9 hom tsis siv tau)

(5) Hauv OP/CL parameter hloov kho interface, luv luv nias lub pob nres kom hloov lub sijhawm (1s/0.1s/0.01s/1min);

(6) Tom qab teeb tsa tag nrho cov kev txwv, ntev nias lub pob teeb tsa kom txuag tau qhov ntsuas qhov ntsuas thiab tawm ntawm qhov chaw teeb tsa.
